Form Filling Simplified
-
Click
to view in detail
Create fully BS compliant certification (BS 7671 18th Edition Amendment 2, BS 5839, BS 5266, PAT) quickly and efficiently.
The software includes the following features to speed up form filling:
-
NEW: BS 7671 18th Edition Amendment 2 Certificates
-
BS 7671 18th Ed (Amd1) EV Charging Point Forms -Click to view in detail
-
Circuit Template Wizard for BS 7671 Certs (see image below).
-
Sign All button Fill all name, position, signature, date, and company address details in a single click.
Click for video Click for screenshot
Contractor Database with auto signature insertion
Auto fill circuit numbers
Option to add data from individual manufacturers with own overcurrent protection values.
Populate single phase or 3-phase circuits quickly to certificate.
Auto calculates Max Zs values
Speed fill inspection schedule and observations.
Dropdown boxes for continuity/insulation resistance in Test Results
What's new in 18th Edition Amendment 2?
Shorter Inspection Schedule
The Electrical Installation Certificate is now much more compact, due to a much shorter Inspection Schedule. This reduces the size of the 1 signature EIC form from 6 pages to 4 pages.
We have given you the option of adding the full Inspection Checklist to the certificate if you wish. (see red text in image below)
Additional RCD columns
18th Edition Amendment 2 introduced additional RCD columns for BS (EN), Type and Rating. This necessitated switching the orientation of the page to landscape. We have managed to retain 24 way boards though, by moving the Codes for Type of Wiring to the right side of the page. This will help reduce the need for continuation sheets.
